How To: Measure Center to Center Spacing for Cabinet Hardware

Center-to-center sizing in cabinet hardware refers to the measurement between the centers of two adjacent mounting holes on a piece of hardware, such as handles, knobs, or pulls used on cabinets, drawers, or furniture. This measurement is essential when replacing or installing new hardware to ensure proper fit and alignment.

To determine the center-to-center measurement, you need to measure the distance between the centers of the two mounting holes.

For example, if you have a cabinet handle with two mounting holes, you would measure the distance between the centers of those holes.

When purchasing new cabinet hardware, it is crucial to match the center-to-center measurement of the new hardware with the existing holes or the intended installation location. This ensures that the new hardware will align correctly with the pre-drilled holes or allows you to drill new holes at the appropriate spacing.

The center-to-center sizing is usually expressed in inches or millimeters. Common measurements include 3 inches (76 mm), 3.75 inches (96 mm), 4 inches (102 mm), and 5 inches (128 mm), although other sizes are also available. It's important to note that the center-to-center sizing may vary between different hardware manufacturers and styles, so it's essential to double-check the measurements before purchasing.

By understanding the center-to-center sizing of cabinet hardware, you can ensure a proper fit and achieve a cohesive look when replacing or installing new hardware on your cabinets or furniture.
